J5CREATE HDMI TO VGA ADAPTER

  • Product Description

    The JDA213S HDMI to VGA adapter allows you to connect the HDMI output from your laptop, Ultrabook, desktop, tablet, Blu-ray, DVD player, digital set-top box, digital camera, video camera or gaming console equipment to the VGA input of a monitor or projector by converting the HDMI video signal from the output device into a VGA output and separate 2-channel analog audio. The adapter supports resolutions including high definition 1080p, up to 1920 x 1200, which eliminates the expense of upgrading a VGA display for the sake of compatibility. The adapter can also increase your productivity by extending your computer's desktop onto a secondary monitor, doubling available workspace. Once you’ve experienced multiple monitors, you’ll never want to go back to a single monitor again.

    Features

    • • Easy-to-use cable
    • • No software required
    • • No power adapter required
    • • Easily make your new HDMI equipment compatible with a VGA display
    • • Supports PC resolutions up to 1920 x 1200 @ 60 Hz (WUXGA) and HDTV resolutions up to 1080p @ 60 Hz
    • • 2-channel analog audio output
    • • Reserved micro USB Type-B power input port, giving the JDA213S the ability to be powered separately if there is no HDMI output device
    • • HDMI receiver compliant with HDMI 1.4 specification
    • • VGA output is compliant with VESA VSIS v1r2 specification

Interface

VGA Output

VGA (15 Pin; High Density D-Sub) Female

Audio Output

3.5 Mm Mini-Jack Female

HDMI Input

HDMI (19 Pin) Male

Power

USB Micro-B (5 Pin) Female 5V

Hardware

Converter Type

Format Converter

Audio

Yes

Performance

Maximum Analog Resolutions

1920 X 1200

Wide Screen Supported

Yes

Audio Specifications

2-Channel Stereo

Physical Specifications

Housing Material

Aluminum

Dimensions

Main Body:
1.6 (W) X 1.8 (H) X 0.6 (D) In.
40 (W) X 45 (H) X 14 (D) Mm
Cable Length: 4 In. / 100 Mm

Weight

Approximately 54g



System Requirements

Device:
HDMI devices including, but not limited to:
• Desktop, Laptop, Ultrabook (PC and Mac®)
• DVD players and Blu-ray players
• Smart TV Box
• Digital camera
• Gaming consoles (PS3 and Xbox)

VGA display devices including, but not limited to:
• Projector
• Display monitor
• TV

Audio devices including, but not limited to:
• Amplifier speaker
• Home Theater

Package Contents

  • JDA213S HDMI to VGA adapter
  • Quick Installation Guide
